RS1-AA2N1

> Life expectancy：

Mechanical≥100 million cycles

Electrical≥10000 cycles

> Features：

-The feel is good, Positions number is clear
-Selection of a variety of input and output
-Selection of a variety of shaft axis length
-A variety of shape size to choose from

> Application:

Electric fan | juicer | electric oven | slow Cooker
water heater | electric heating bath bully

air conditioner Such as household appliances

industrial appliances and other electrical equipment

Rsone serial selector switch series

technical parameters：

1. Insulation resistance: ≥100MΩ（500VDC）

2. Contact resistance: ≤50mΩ (Lnitial value)

3. Test voltage：

Between terminals of the same polarity：

AC1000V,50/60Hz,1min

Between current-carrying metal parts and ground(case),

and between each terminal and non-current-carrying

metal parts：AC2000V,50/60Hz,1min

4. Life expectancy：

Mechanical≥100 million cycles

Electrical≥10000 cycles

Note：With line switch and function can be customized

according to customer requirements
