RS3-AE34A21

> Life expectancy：

Mechanical≥100 million cycles

Electrical≥10000 cycles

> Features：

-The feel is good, Positions number is clear
-Selection of a variety of input and output
-Selection of a variety of shaft axis length
-A variety of shape size to choose from
-Spare parts are imported material to ensure the

-performance of our products

> Application:

Electric heaters | electric heating oil heater |

water heater | electronic oven | electric heating

bath bully | conditioner Such as household appliances

| industrial appliances and other electrical equipment

Rsthree serial selector switch series

technical parameters：

1. Insulation resistance: ≥100MΩ（500VDC）

2. Contact resistance: ≤50mΩ (Lnitial value)

3. Test voltage：

Between terminals of the same polarity：

AC1000V,50/60Hz,1min

Between current-carrying metal parts and ground(case),

and between each terminal and non-current-carrying

metal parts：AC2000V,50/60Hz,1min

4. Life expectancy：

Mechanical≥100 million cycles

Electrical≥10000 cycles

Note：Function can be customized according to

customer requirements
