PRODUCTSdisplay Location：Home>Product>Ss1 Series Toggle Switch>SS1
Rsone serial selector switch series
technical parameters:
1. Insulation resistance:≥100MΩ（50VDC）
2. Contact resistance:≤50mΩ (Lnitial value)
3. Test voltage:
End-End:750VAC/5S,5mA
Shell with end:1500VAC/5S,5mA
4. Life expectancy:Electrical≥10000 cycles
5.Electrical raring:3A,250/250V,T85
6.PTI:175V
Note：Function can be customized according to
customer requirements
description
